Насос серии FTD

Вертикальные одноступенчатые центробежные насосы. Легкая установка в линию (in-line).
Специальное механическое уплотнение для эксплуатации. в системах отопления, кондиционирования и других системах климатизации.
Насосы оснащены высокоэффективным двигателем IЕЗ с классом защиты IPSS F.
Долговечный подшипник, износостойкое механическое уплотнение.
Антикоррозийное покрытие насоса.

Эксплуатационные ограничения

Непрерывный режим работы S 1
Температура жидкости от -10°С до+ 120°С
Температура воздуха от-10°С до +60°C
Максимальное рабочее давление 16 бар

Модель	DN	Мощность		Q=Подача
				л/мин 0	33	83	133	167	208	267	333	417	500	583	667	750	833	1000	1167	1333	1500	1667
				м³/ч 0	2	5	8	10	12.5	16	20	25	30	35	40	45	50	60	70	80	90	100

	мм	кВт	лс	H=Напор (м)
FTD32-14G/2	32×32	0.75	1	16	16	15.4	14	12.6	9.3
FTD32-18G/2	32×32	1.1	1.5	19.8	19.6	19.1	18	17.2	14.6
FTD32-21G/2	32×32	1.5	2	25.3	25.3	24.6	23.6	22.6	21	18
FTD32-26G/2	32×32	2.2	3	28.7	28.7	28.3	27.7	27.1	26	23.2
FTD32-33G/2	32×32	3	4	36	35.8	35.3	34.7	34.1	33	30.6
FTD32-40G/2	32×32	4	5.5	41.3	41.3	41.2	41	40.7	40	37
FTD32-50G/2	32×32	5.5	7.5	51	51	50.9	50.7	50.5	50	47.3
FTD40-14G/2	40×40	0.75	1	16	15.8	15.1	14	13.9	10.2
FTD40-16G/2	40×40	1.1	1.5	19.8	19.8	18.9	18.2	17.5	16	11.4
FTD40-21G/2	40×40	1.5	2	24	23.9	23.6	22.9	22.2	21	17.1
FTD40-20G/2	40×40	2.2	3	23	23	22.7	22.5	22.2	22	21.3	20	16.6
FTD40-26G/2	40×40	3	4	29	29	28.9	28.6	28.2	27.8	26.7	25	21.9
FTD40-30G/2	40×40	4	5.5	34.9	34.9	34.7	34.5	34.4	34.1	33.4	32.2	30	26.4
FTD40-36G/2	40×40	5.5	7.5	41	41	40.9	41	40.9	40.7	39.8	38.5	36	32.3
FTD40-48G/2	40×40	7.5	10	52	52	51.6	51.6	51.6	51.4	51.1	50.3	48	42.5
FTD50-32G/2	50×50	3	4	35	35	34.6	34	33.2	33	29.4	23.3
FTD50-39G/2	50×50	4	5.5	42	42	41.7	41	40.2	39	36.2	31.2
FTD50-49G/2	50×50	5.5	7.5	52	52	51.2	50.3	50	49	46.4	41.5
FTD50-59G/2	50×50	7.5	10	62.3	62.3	62.1	61.1	60.3	59	55	45.7
FTD50-80G/2	50×50	11	15	82	82	81.7	81.5	81.1	80	77	71.6
FTD50-12G/2	50×50	1.1	1.5	13		13	13	12.9	12.7	12	10.7
FTD50-15G/2	50×50	1.5	2	16.1		16.1	16.1	16.1	15.9	15.6	15	13.3
FTD50-18G/2	50×50	2.2	3	20.2		20.2	20.1	20	19.9	19.6	19	18	16.4
FTD50-24G/2	50×50	3	4	25.9		25.9	25.8	25.7	25.5	25.2	24.8	24	22.6
FTD50-28G/2	50×50	4	5.5	29.5		29.5	29.5	29.5	29.5	29.3	29.2	28.8	28	26.4
FTD50-35G/2	50×50	5.5	7.5	36.3		36.3	36.3	36.2	36.2	36	35.9	35.5	35	34.1	32.2
FTD50-40G/2	50×50	7.5	10	42.5		42.5	42.5	42.4	42.4	42.2	42.1	41.7	41	40	38.5	36.4
FTD50-50G/2	50×50	11	15	53		53	53	52.9	52.8	52.6	52.4	52	51.5	50.9	50	48.7	48.4
FTD50-60G/2	50×50	15	20	65.8		65.8	65.8	65.7	65.7	65.7	65.6	65.3	64.7	63.9	62.8	61.6	60	53.2
FTD50-70G/2	50×50	18.5	25	73.7		73.7	73.7	73.6	73.6	73.4	73.3	73.1	72.9	72.5	72	71.2	70	65.4
FTD50-81G/2	50×50	22	30	85.5		85.5	85.4	85.3	85.2	85	84.8	84.5	84	83.5	82.8	82.1	81	77.1
FTD65-37G/2	65×65	5.5	7.5	39.6		39.6	39.5	39.3	39	38.6	38.2	37	35	32.1
FTD65-48G/2	65×65	7.5	10	50.4		50.4	50.4	50.3	50	49.7	49.3	48	45.9	42.6
FTD65-15G/2	65×65	2.2	3	17.7				17.1	16.9	16.7	16.4	15.7	15	13.2	11.3
FTD65-20G/2	65×65	3	4	22				21.8	21.6	21.4	21.2	20.6	20	18.7	17.4
FTD65-22G/2	65×65	4	5.5	25.8				25.1	25	24.9	24.8	24.4	23.9	23	22	20.2	18.4
FTD65-30G/2	65×65	5.5	7.5	32				31.5	31.5	31.4	31.3	31.2	31	30.5	30	28.7	27.3
FTD65-34G/2	65×65	7.5	10	38.5				38.3	38.2	38.1	38	37.7	37.4	36.8	36.1	35.1	34	30.5
FTD65-41G/2	65×65	11	15	45				44.8	44.8	44.7	44.7	44.6	44.4	44	43.5	42.3	41	36.1
FTD65-51G/2	65×65	15	20	54				53.7	53.7	53.6	53.5	53.3	53.1	52.8	52.4	51.7	51	48
FTD65-61G/2	65×65	18.5	25	64.5				64.5	64.5	64.5	64.5	64.5	64.4	64	63.5	62.3	61	56.5	47.6
FTD65-68G/2	65×65	22	30	70.5				70.5	70.5	70.5	70.5	70.4	70.3	70	69.6	68.8	68	63.8	58	48.6
FTD65-85G/2	65×65	30	40	86.7				86.7	86.7	86.7	86.7	86.6	86.5	86.3	86	85.5	85	82.5	78.5	72.4	63.3
FTD80-41G/2	80×80	11	15	42.3				42.3	42.3	42.2	42.2	42.2	42.1	42	41.8	41.4	41	38.4
FTD80-48G/2	80×80	15	20	49.4				49.4	49.4	49.4	49.4	49.4	49.3	49.2	49	48.5	48	46	42.8
FTD80-13G/2	80×80	3	4	18.9				18.9	18.9	18.8	18.6	18.2	17.8	17.1	16.3	14.7	13	8
FTD80-18G/2	80×80	4	5.5	23.2				23.2	23.2	23.1	23	22.6	22.2	21.4	20.6	19.3	18	12.9	6
FTD80-23G/2	80×80	5.5	7.5	28.2				28.2	28.2	28.1	28	27.5	27	26.1	25.2	24.1	23	19.5	13.9	7.1
FTD80-29G/2	80×80	7.5	10	33				33	33	32.9	32.8	32.5	32.1	31.5	30.9	30	29	26.7	23.2	17.8
FTD80-32G/2	80×80	11	15	36.2				36.2	36.2	36.2	36.2	36.1	36	35.8	35.6	35.3	34.9	33.8	32	28.7	24.4	19.3
FTD80-38G/2	80×80	15	20	45.7				45.7	45.9	45.9	45.9	46.1	46.2	46.1	45.9	45.5	45	43.3	41.1	38	33.8	28.8
FTD80-47G/2	80×80	18.5	25	53.2				53.2	53.4	53.4	53.4	53.4	53.4	53.3	53.2	52.8	52.4	51.2	49.4	47	43.2	37.6
FTD80-54G/2	80×80	22	30	59.7				59.7	59.9	59.9	59.9	60	60	59.9	59.8	59.5	59.2	58	56.2	54	50.9	46.9
FTD80-67G/2	80×80	30	40	71				71	70.9	70.9	70.9	70.9	70.8	70.7	70.6	70.5	70.4	69.9	68.7	67	65	62.3
Модель	DN	Мощность		Q=Подача
				л/мин 0	833	1000	1167	1333	1667	2000	2167	2333	2667	3333	4000	5000	6000	6667	8000	8333	10000	10500	12500
				м³/ч 0	50	60	70	80	100	120	130	140	160	200	240	300	360	400	480	500	600	630	750

	мм	кВт	лс	H=Напор (м)
FTD100-9/2	100×100	2.2	3	12.8	9	6.8	4.4	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–
FTD100-15/2	100×100	4	5.5	18.5	16.2	15	13.4	11	–	–	–	–	–	–	–	–	–	–	–	–	–	–	–
FTD100-17G/2	100×100	5.5	7.5	22	20	19.4	18.4	17	12.3	–	–	–	–	–	–	–	–	–	–	–	–	–	–
FTD100-22G/2	100×100	7.5	10	26	24.1	23.6	22.9	22	18.6	–	–	–	–	–	–	–	–	–	–	–	–	–	–
FTD100-27/2	100×100	11	15	31.7	30.7	30.3	29.8	29.2	27	23.6	20.8	–	–	–	–	–	–	–	–	–	–	–	–
FTD100-33/2	100×100	15	20	37.2	36.2	35.8	35.3	34.7	33	30.1	27.9	–	–	–	–	–	–	–	–	–	–	–	–
FTD100-40G/2	100×100	18.5	25	44	43.7	43.4	42.9	42.1	40	36.6	34.3	–	–	–	–	–	–	–	–	–	–	–	–
FTD100-48G/2	100×100	22	30	51	50.8	50.6	50.2	49.7	48	45.5	43.5	–	–	–	–	–	–	–	–	–	–	–	–
FTD100-52G/2	100×100	30	40	59	58.2	57.8	57.3	56.9	55.8	53.9	52	49.5	40.8	–	–	–	–	–	–	–	–	–	–
FTD125-11G/4	125×125	5.5	7.5	13.8	13.3	13.1	12.9	12.6	11.9	11	10.4	9.8	8.1	–	–	–	–	–	–	–	–	–	–
FTD125-14G/4	125×125	7.5	10	15.9	15.3	15.2	15.1	15	14.7	14	13.4	12.8	10.9	–	–	–	–	–	–	–	–	–	–
FTD125-19G/4	125×125	11	15	22	21.4	21.3	21.2	21.1	20.7	19.9	19.5	19	17.6	–	–	–	–	–	–	–	–	–	–
FTD125-22G/4	125×125	15	20	26.6	26.6	26.5	26.4	26.2	25.7	24.9	24.3	23.7	22	16.7	–	–	–	–	–	–	–	–	–
FTD125-28G/4	125×125	18.5	25	31	30.9	30.8	30.8	30.7	30.5	30.1	29.7	29.3	28	22.2	–	–	–	–	–	–	–	–	–
FTD125-32G/4	125×125	22	30	34.6	34.6	34.6	34.6	34.5	34.4	34	33.7	33.3	32	27.3	–	–	–	–	–	–	–	–	–
FTD125-40G/4	125×125	30	40	46.1	46.1	46	45.9	45.7	45.2	44.3	43.4	42.5	40	32.5	–	–	–	–	–	–	–	–	–
FTD125-48G/4	125×125	37	50	53	52.5	52.3	52	51.9	515	50.9	50.4	49.9	48	41	–	–	–	–	–	–	–	–	–
FTD150-12.5G/4	150×150	11	15	16.1	16.1	16.1	15.9	15.8	15.6	15.4	15.3	15.1	14.6	12.5	7.6	–	–	–	–	–	–	–	–
FTD150-17G/4	150×150	15	20	19.5	19.5	19.5	19.4	19.4	19.2	19.1	19	18.8	18.4	17	12.6	–	–	–	–	–	–	–	–
FTD150-22G/4	150×150	18.5	25	23.6	23.6	23.6	23.5	23.4	23.4	23.2	23.2	23.1	23	22	18.7	–	–	–	–	–	–	–	–
FTD150-25/4	150×150	22	30	28.1	28.1	28.1	28	28	27.9	27.7	27.5	273	26.8	25	213	–	–	–	–	–	–	–	–
FTD150-33/4	150×150	30	40	35.5	35.5	35.5	35.4	35.4	35.3	35.1	35	34.8	34.4	33	29.6	–	–	–	–	–	–	–	–
FTD150-40/4	150×150	37	50	43.1	43.1	43.1	43	43	42.9	42.7	42.6	42.4	41.9	40	36.2	–	–	–	–	–	–	–	–
FTD150-50/4	150×150	45	60	52.4	52.4	52.4	52.3	52.2	52	51.9	51.8	51.7	51.4	50	46.7	–	–	–	–	–	–	–	–
FTD200-16/4	200×200	18.5	25	22.5	–	–	–	–	22.5	22.4	22.3	22.3	22	20.7	19.4	16	11.5	–	–	–	–	–	–
FTD200-19/4	200×200	22	30	24.4	–	–	–	–	24.4	24.3	24.3	24.3	24	23	22	19	15	–	–	–	–	–	–
FTD200-24/4	200×200	30	40	26.1	–	–	–	–	26.1	26	25.9	25.9	25.8	25.5	25.1	24	21.5	–	–	–	–	–	–
FTD200-31/4	200×200	37	50	35.4	–	–	–	–	35.4	35.3	35.2	35.1	34.8	34	33.2	31	27.6	–	–	–	–	–	–
FTD200-36/4	200×200	45	60	39.5	–	–	–	–	39.5	39.4	39.3	39.2	39	38.5	37.9	36	33	–	–	–	–	–	–
FTD200-47/4	200×200	55	75	50.6	–	–	–	–	50.6	50.5	50.4	50.3	50.1	49.5	48.9	47	42.4	–	–	–	–	–	–
FTD200-53/4	200×200	75	100	55.7	–	–	–	–	55.7	55.7	55.7	55.7	55.6	55.2	54.8	53	50	–	–	–	–	–	–
FTD200-12.5/4	200×200	22	30	17.9	–	–	–	–	–	–	–	–	17.2	16.9	16.5	15.5	14	12.5	8	–	–	–	–
FTD200-20/4	200×200	30	40	24.8	–	–	–	–	–	–	–	–	24.6	24.4	24	23.2	21.7	20	14.2	–	–	–	–
FTD200-23/4	200×200	37	50	28.3	–	–	–	–	–	–	–	–	28.1	27.8	27.4	26.4	24.8	23	18.2	–	–	–	–
FTD200-2714	200×200	45	60	32.5	–	–	–	–	–	–	–	–	32.1	31.7	31.2	30.1	28.4	27	22.5	–	–	–	–
FTD200-32/4	200×200	55	75	38	–	–	–	–	–	–	–	–	37.5	37.1	36.5	35.2	33.3	32	27.7	–	–	–	–
FTD200-43/4	200×200	75	100	47.5	–	–	–	–	–	–	–	–	47	46.7	46.4	45.6	44.4	43	38.6	–	–	–	–
FTD200-50/4	200×200	90	125	53	–	–	–	–	–	–	–	–	52.9	52.8	52.6	52	51	50	45.5	–	–	–	–
FTD250-16/4	250×250	30	40	20.8	–	–	–	–	–	–	–	–	20.5	20.4	20.1	19.6	18.8	18.2	16.5	16	13.3	–	–
FTD250-1914	250×250	37	50	23.5	–	–	–	–	–	–	–	–	22.7	22.4	22.1	21.7	21.2	20.8	19.4	19	16.6	–	–
FTD250-22/4	250×250	45	60	26	–	–	–	–	–	–	–	–	25.7	25.3	25.1	24.7	24.2	23.8	22.4	22	19.7	–	–
FTD250-29/4	250×250	55	75	35	–	–	–	–	–	–	–	–	34.6	34.4	34.4	34.4	32.8	31.8	29.6	29	23.9	–	–
FTD250-36/4	250×250	75	100	39.5	–	–	–	–	–	–	–	–	39.1	38.8	38.6	38.2	37.7	37.3	36.3	36	32.5	–	–
FTD250-4714	250×250	90	125	54	–	–	–	–	–	–	–	–	53.3	53.1	53	52.4	51.3	50.6	47.9	47	42.5	–	–
FTD250-56/4	250×250	110	150	62	–	–	–	–	–	–	–	–	61.6	61.4	60.9	60.2	59.2	58.6	56.6	56	51	–	–
FTD250-12.5/4	250×250	30	40	19.5	–	–	–	–	–	–	–	–	–	–	18.4	17.9	17.2	16.7	15.5	15.2	13.2	12.5	8.7
FTD250-14/4	250×250	37	50	21	–	–	–	–	–	–	–	–	–	–	20	19.5	18.9	18.4	17.5	17.2	15.6	14	11.6
FTD250-17/4	250×250	45	60	22.8	–	–	–	–	–	–	–	–	–	–	21.8	21.3	20.8	20.3	19.4	19.1	17.6	17	13.4
FTD250-20/4	250×250	55	75	25.5	–	–	–	–	–	–	–	–	–	–	24.5	24.1	23.7	23.3	22.4	22.1	20.5	20	16.5
FTD250-26/4	250×250	75	100	32.2	–	–	–	–	–	–	–	–	–	–	31.7	31.1	30.6	30.1	29.1	28.8	26.8	26	21.9
FTD250-32/4	250×250	90	125	37.7	–	–	–	–	–	–	–	–	–	–	36.7	36.3	35.7	35.3	34.3	34	32.6	32	28.4
FTD250-40/4	250×250	110	150	46.5	–	–	–	–	–	–	–	–	–	–	46	45.5	44.9	44.4	43.4	43	40.8	40	35.5
FTD250-50/4	250×250	132	180	56.2	–	–	–	–	–	–	–	–	–	–	55.6	55.2	54.6	54.1	53.2	52.9	50.9	50	45.4
